Trim Winder Machine
slitting machine
Our Trim Removal System – TRIM WINDER MACHINE  is simple equipment using latest technology, to help you manage the trims effectively and efficiently for better profitability.
Trim Winder Machine Slitting Machine Trim Winder Machine Trim Winder Machine
Technical Specification
BLUE EYE Trim winders incorporate many features for high reliability of trim winding. The precision electromechanical traversing system is maintenance free with operator control of the traversing rate which remains constant regardless of the line speed or the spool diameter. This, together with the inbuilt pineapple winding technology, ensures optimum winding of the trim and therefore increases the reliability. The lightweight web guide roll assembly traverses for high speed operation with the spool running in a fixed position.
Each trim winder is driven by its own variable speed motor running under closed loop tension control from a precision dancer.
Alternatively, where space is at a premium, the winder motor can be operated under direct torque control. Full sized rolls can be unloaded quickly and the winder restarted.Winders are fitted with a remote air inflation system on winding shafts for paper cores or a quick release mechanism on shafts.
Standard Features Optional
product-icon Fully mechanical controlled traversing.
product-icon Trapezoidal (Pineapple) winding profile.
product-icon Cantilevered winding shaft.
product-icon Closed loop speed control.
product-icon Traverse winding.
product-icon Variable traversing rate.
product-icon Quality engineered and manufactured.
product-icon Save your Electricity.
product-icon Keep your floor clean.
product-icon Pull roll for constant pull during roll change.
slitting machine suppliers Winding to minimize waste.
trim winder machine Winding of 2 trims on one winder.
coreless trim winder machine Winded roll use for making rope.
The motion control drive is controlled by a digital inverter drive, capable of both driving and stopping the motor. Material is fed by dancer for tension control, equipped with a position feedback through ultrasonic sensor. Together with the PID controls on the trim winder control board, this provides a speed reference for the motion control drive. The system operates to maintain the dancer in a fixed position, thus providing static rewinding tension.
The tension is set by the position of the dancer. When the dancer is close to the refrence, the trim tension is high. When it’s furthest away from the refrence, the tension is low. Dancer position is set by the internal set tension in tourqe mode. The dancer is mounted on a cross travel mechanism, and acts as a layering guide to the trim.
The cross travel is controlled by a lead motion liner guide ways with automatic end reversing, so that dancer  always rotates in motion control. The traverse motor is controlled by a digital inverter drive operating directly from the AC supply. A setpoint isolator on the control board links the winding motor speed reference with the traverse motor so that they operate in unison.
The winder can either be stopped and started from the remote control push buttons or linked directly to the main feed machine. A trim break detector on the control operates three seconds after start up to stop the winder if the dancer hasn't been pulled off its end stop position.
